Bas TV Stand

1. Check Your Boxes!

Before diving in, make sure both boxes arrived safely. Check for any signs of damage. If everything looks good, you’re all set! If not, reach out to our customer support, and we’ll help sort it out.

2. Set Up Your Workspace

Choose a soft surface like a blanket, carpet, or the cardboard from the box to protect your furniture while assembling. We recommend grabbing a friend to help – Bas is a bit bulky, and two pairs of hands make things easier and safer.

If you encounter any problems, we are here to help, so please reach out to us!

Step 1: Check Your Parts

Make sure you’ve got everything:

• 1x base panel - A
• 1x top panel - B
• 1x back panel - C
• 1x shelf - D
• 5x side panels - E,F,G,H,I
• 4x hinges
• 8x screws
• 6x adjustable legs

Step 2: Attach the Legs

Take the base panel (A) and place it upside down. Screw the 6 adjustable legs into the pre-drilled holes. Once they’re securely attached, flip the base right-side up and set it aside – we’ll come back to it later.

Step 3.

Grab the back panel (C) (the one with the cable hole) and one inner side panel (H). The assembly system clicks together and is tightened with an Allen key – no extra screws required!

Step 4: Create the "T" Structure

Attach the shelf (D) to the inner side panel (G) to form a "T" shape. Tighten all (2) connections.

Step 5: Combine the "T" with the Back

Now, connect the "T" structure to the back panel (C). Tighten the (3) fittings.

Step 6: Add the Left Side Panel

Attach the left outer panel (E) to the shelf. Tighten the (3) connectors in the designated holes.

Step 7: Connect to the Base

Bring the assembled structure over to the prepared base panel (A). Attach and tighten the (9) connections securely.

Step 8: Add the Right Side Panel

Now, attach the right outer panel (I) to the base and tighten everything into place.

Step 9: Attach the Top Panel

Time for the top panel (B)! Align it with the assembled structure, ensuring all connectors fit perfectly. Tighten each (11) connection securely.
Hint: If some parts don’t line up easily, slightly loosen previous connections and tighten them again once everything is in place.

Step 10: Install the Hinges

Grab the sliding front panel (F) and attach the hinges into the pre-drilled holes. Use two screws per hinge (8 total).
Important: Make sure the yellow-marked hinge with the circle is installed on the bottom.

Step 11: Mount the Front Panel

Here comes the fun part – attaching the front panel! Ensure the hinges are correctly positioned with matching pairs on each side. The yellow-marked hinges with the circle must be at the bottom.
To attach:

1. Hold the top hinges and release the protruding latches downward to clear the way for installation.
2. Align the bottom hinges into the linear slot first.
3. Once the bottom is secured, align the top hinges and release the latches to lock everything in place.

Step 12: Done and Dusted!

Voila! Your Bas TV stand is ready to shine. If anything feels loose, go back and tighten the connections. Don’t forget to adjust the legs to ensure perfect stability.

Enjoy your new piece of furniture – we hope it feels as amazing as it looks!



If anything was unclear, incorrect, or poorly explained, we would greatly appreciate your feedback.





Now double-check and share with us your work.

Once you have completed assembling, double-check your work to ensure that everything is in place and secure. If everything is save and sound we would love to see the furniture in your unique spaces.
